Model 3580A
ADJUSTMENT
PROCEDURES
Section V
NOTE
Always select a
range
on the multimeter
so
that
a
range
change
is
not  necessary  for  reading
2915  volts.  For  instance,  when  using  the
-hp-
34740A/34702A  Multimeter  and  11045A
probe,
put
the  34
702A
on  the  10 volt
range,
not
the 1 volt
range.
b.  Turn the 3580A
POWER
switch to OFF and remove
the  gray  metal  shield  on  the  rear  panel
of
the  3580A.
Remove  the  plastic shield on  the CRT connector to expose
the  wiring  terminals.  Turn  the  3580A POWER  switch  to
ON
(AC).  HIGH  VOLTAGE  LEADS  ARE
NOW
EX-
POSED.
c.  With  the high  voltage  probe  and digital  multimeter,
measure  the  de voltage present at pin 2 (yellow lead)
of
the
CRT  connector.  Adjust  A8Rl  (HV  ADJ.)  for  a  voltage
reading
of
- 2915  volts  ± 3  volts.
If
you  calibrated your
own probe
as
described in  Step a,  adjust  the voltage
to
the
appropriate value, ±  1
%.
NOTE
This  adjustment  affects  the  Sweep  Alignment
and Dial Calibration
(Paragraph
5-63),
as
well
as
the  Amplitude  Calibration
(Paragraph
5-
74
).
Repeat  the  Frequency  Tests
(Paragraph
5-9)
and  Amplitude  Tests
(Paragraph
5-18)
of
the
Performance  Tests  to  determine
if
these
addi-
tional adjustments need  to
be
made.
d.  Turn the 3580APOWER switch
to
OFF  and replace
the  two CRT shields  removed in  Step b).  Turn the 3580A
POWER
switch back
to
ON
(AC).
5-58.
Display
Adjustments.
5-59.  These  adjustments  set  the  proper  intensity  limits,
astigmatism,  and  trace  alignment  on  the  CRT.  In  many
cases,  these  display  parameters
will
require no adjustments.
5-60.  Intensity  Limit Adjustment.
a.
Turn  the  3580A  power  switch  to OFF. Unplug the
Al3J3
connector. Remove  the nylon access screw from the
top
of
the  high voltage  power supply box. Turn the  front
panel  INTENSITY  control  to  the
"9
o'clock"  position.
Turn the 3580A
POWER
switch back
to
ON
(ac).
WARNING
I
The  voltages  present  inside  the  high  voltage
power  supply  box
can
cause  serious  injury.
Never  place
an
uninsulated conductive  tool or
object inside  this  box  while  the  instrument
is
turned on.
b.  Using
an
insulated non-metalic tuning wand, such
as
-hp- Part  No.  8710-0033,  adjust  Al
lRl
(INTENSITY
UMIT, inside  high  voltage  power supply  box)
so
that the
dot on the CRT just disappears.
c.  Replace  the  nylon  screw  in  the  high  voltage  power
supply box.
5-61.  Astigmatism Adjustment.
a.
Adjust  the  front  panel  focus  fully
CCW.
Turn  the
front  panel  INTENSITY  adjust
to
about
10
or
11
o'clock
so
that the  dot  on  the  CRT
is
bright  enough  to  see,  but
does not form a "halo".
b.  Adjust  A8R2 (ASTIG.  ADJ.) for  the largest  circular
dot.
c.  Turn the 3580A
POWER
switch to OFF. Reconnect
the  connector  to
Al3J3.
Turn the 3580A POWER switch
back to
ON
(ac).
5-62.,
Trace
Alignment Adjustment.
a.
Position  the  3580A front  panel controls
as
follows:
ADAPTIVE
SWEEP
...........•..
Centered
DISPLAY  . . . • . . . .
All
pushbuttons released
AMPLITUDE
MODE
.......
LOG 10 dB/DIV
AMPLITUDE REF LEVEL
.......
NORMAL
dBv/LIN -dBm 600 n
............
dBv/LIN
INPUT SENSITIVITY  . . . . . . . . . . . .  -30
dB
VERNIER (Amplitude)
............
CAL
(Fully
CW)
FREQUENCY
.................
00.0
Hz
START-CTR
...................
START
RESOLUTION
BANDWIDTH
. . . . . .  300
Hz
DISPLAY SMOOTHING
.............
MIN
FREQ. SPAN/DIV
..............
0.2
KHz
SWEEP
TIME/DIV  . . . . . . . . . . . . .  0.1
SEC
SWEEP
MODE
.....................
REP
Option 002: Set dBm 900 Q/LIN -
dBm
600 Q
switch
to
dBm
900 Q;  set  INPUT
MODE
switch
to
UNBAL.
b.  Adjust the front panel ADAPTIVE
SWEEP
for a line
in the middle
of
the display. Adjust the front panel FOCUS
control for the narrowest and sharpest line.
c.  Adjust  A13R5  (TRACE  ALIGN) for  a level  trace.
If
unable
to
achieve  this, switch
Al3Sl
and readjust
Al3R5.
5-63.
Sweep
Alignment
and
Dial
Calibration.
5-64.  These  adjustments  calibrate  the  front  panel  FRE-
QUENCY  dial  plus  align  the frequency  sweep limits.  They
should
be
done
if
the  Frequency Tests (Paragraph 5-9) or
Sweep  Tests  (Paragraph  5-13)
of
the  Performance  Tests
cannot  be  passed  by  the  instrument.  In  addition,  the
adjustment should  be  made
if
the high voltage  supply
was
previously adjusted.
5-17
