Chapter 7
Removing and Replacing Components
Front Bezel
144
Front Bezel
The server does not have to be turned off to remove the front bezel.
Opening the control panel door provides access to the following components:
• Power switch
• System LEDs
Figure 7-3 Removing and Replacing the Front Bezel
Removing the Front Bezel
To remove the front bezel, perform the following steps:
Step 1. Grasp the front bezel at the outer edges and pull straight out.
Replacing the Front Bezel
To Replace the front bezel, perform the following steps:
Step 1. Push the front bezel straight into the chassis until it snaps into place.
