Chapter 7
Removing and Replacing Components
DVD I/O Board
213
Step 5. Remove the processor extender board. See “Processor Extender Board” on page 160.
Step 6. Using a torx #15 driver, remove the two torx screws holding the DVD I/O board cover plate to the chassis and
remove the cover plate.
Step 7. Unfasten the release clip attaching the DVD I/O board to the chassis. and remove the I/O board from the chassis.
Step 8. Lift out the DVD I/O board and remove the midplane riser board connector cable and remove the DVD I/O board
from the chassis.
Replacing a DVD I/O Board
To replace a DVD I/O board, perform the following steps:
Step 1. Replace the DVD I/O board into the chassis and plug in the midplane riser board connector cable.
Step 2. Replace DVD I/O board to the chassis by refastening the release clip.
Step 3. Replace the cover plate using the two torx #15 screws and a torx #15 driver.
Step 4. Replace the processor extender board.
Step 5. Replace the memory extender board.
Step 6. Replace the front and top covers.
Step 7. Replace the front bezel.
Step 8. If rack mounted, slide the HP Server into the rack until it stops.
