Chapter 7
Removing and Replacing Components
SCSI Backplane Board
198
SCSI Backplane Board
The SCSI backplane board is attached to the rear of the disk media housing at the front, right side of the chassis.
WARNING Ensure that the system is powered down and all power sources have been disconnected from the server
prior to removing or replacing the SCSI backplane.
Voltages are present at various locations within the server whenever an AC power source is connected.
This voltage is present even when the main power switch is in the off position.
Failure to observe this warning could result in personal injury or damage to equipment.
CAUTION Failure to properly complete the steps in this procedure will result in erratic system behavior or system failure.
For assistance with this procedure contact your local HP Authorized Service Provider.
