Chapter 7
Removing and Replacing Components
I/O Baseboard Assembly
172
NOTE The I/O baseboard assembly is large, so be careful when lifting it out of the server chassis.
Figure 7-18 I/O Board Locking Lever
OPEN
CLOSE
