Chapter 4
Installing Additional Components and Configuring
Hot-Plug PCI-X
60
Step 10. Push the HP Server all the way back into the rack until it stops.
Figure 4-16PCI-X OLX Divider Layout
PCI-X card latch
closed position
Manual retention
latch—closed
PCI-X card latch
open position
Manual retention
latch—open
Power LED
light pipe
Attention button
Attention LED
light pipe
