Chapter 9
227
9 Specifications
Introduction
This chapter provides the power requirements, operating conditions (environmental requirements), physical requirements,
hardware specifications, and video resolutions of the hp Integrity rx4640. The following tables provide the specifications
required for normal operation of the hp Integrity rx4640.
NOTE The specifications and requirements for the power supply and environment can vary if you install a mass
storage device in the server that has more stringent environmental limits than required for the HP Server.
Ensure that the operating environment for any mass storage devices you intend to install are compatible with
the server environmental requirements.
Hardware Specifications
Table 9-1 Hardware Specifications
Micro-processors Intel Itanium (up to 4 processors):
1.1 GHz dual processor module 32MB Level 4 cache. Up to 4 modules or 8 processors
1.3 GHz/3MB
1.5 GHz/6MB
Memory Supports up to eight Double Data Rate (DDR) registered ECC Memory, in PC1600 DIMMs.
Supported DDR DIMM sizes: 128MB, 256MB, 513MB, 1GB, and 2GB. Requires DIMMs to
be added in quads of equal capacity.
Video Embedded
SCSI Integrated Ultra-3 SCSI dual channel controller; 80 MB/s transfer rate with two 68-pin
connectors.
integrated hp raid
controller
Optional.
LAN PCI Gigabit, Fast Ethernet Controller; with Wake-on-LAN enabled/disabled via BIOS setup.
PCI Slots Four 64-bit PCI slots, 66MHz slots
Two 64-bit PCI-X slots, 133 MHz slots.
Core I/O Three serial ports, 2 USB ports, Integrated RJ-45 LAN .
DVD-ROM DVD-R/CD-ROM drive; IDE interface; 48x speed.
Mass Storage Maximum Internal Storage: Two 73MB, 15K drive.
External Storage 2 external SCSI ports
Power Supply N+1 configuration, redundant 200-240 VAC power supply (optional).
