HP Integrity rx4640 - Figure 7-22 PCI-X OLX Divider Layout

Chapter 7
Removing and Replacing Components
Hot-Plug PCI-X
183
Step 10. Push the HP Server all the way back into the rack until it stops.
Figure 7-22PCI-X OLX Divider Layout
PCI-X card latch
closed position
Manual retention
latch—closed
PCI-X card latch
open position
Manual retention
latch—open
Power LED
light pipe
Attention button
Attention LED
light pipe
