Chapter 3
29
3 External Connectors
Connector Pinouts
The following ports and connectors are found on the rear panel of the hp Integrity rx4640 Server. The SCSI Host Bus Adapter
card in slot 1 and the Gigabit Ethernet card in slot 2 are factory installed.
Figure 3-1 Rear View
Universal Serial Bus (USB) Ports
Figure 3-2 USB Port Connector
Table 3-1 USB Pinouts
Pin Number Signal Description
1+5VDC
2MR
HBA, Ultra 3 SCSI, 68 Pin Gigabit Ethernet LAN Port
3 Serial Ports VGA Port Management Processor
LAN Port
USB Ports
Local Ax Remote
1
2
3
4
1
2
3
4
