Chapter 8
223
8 Parts Information
Field Replaceable Parts (FRU) List
The items in this list and the corresponding item numbers are the Field replaceable Units (FRUs) for the hp Integrity rx4640
Server.
NOTE The item numbers listed below are used with the part illustrations in order to identify the nomenclature of the
part. Part numbers are found by using the part nomenclature from this list to select the correct part from the
HP Partsurfer. If a system board needs to be replaced, remove processors, DIMMs, and adapter boards and
transfer these to the new board. Ensure all jumper and switch settings on the old board are transferred to the
new board.
Table 8-1 Field Replaceable Parts (FRU) List
Item No. Description
Part Number
Replacement
Part Number
Exchange
Cable
A6961-63006 Cable, Internal SCSI A6961-63006 None
A6961-63005 Cable, QuickFind Diagnostic to Midplane A6961-63005 None
A6961-63004 Cable, Power Distribution to Midplane Ribbon A6961-63004 None
A6961-63003 Cable, Power Distribution to Midplane 10 pin A6961-63003 None
A6961-63011 Cable, SCSI Controller Jumper (Simplex only) A6961-63011 None
A6961-63008 Cable, SCSI Backplane to Midplane A6961-63008 None
A6961-63002 Cable, Display to IDE to Midplane A6961-63002 None
PCA Boards
A6961-60007 PCA, Processor Extender A6961-67007 A6961-69007
A6961-60001 PCA, I/O baseboard (includes VRMs) A6961-67001 A6961-69001
A6961-60201 PCA, I/O Baseboard (includes VRMs) supports Wake On Lan
Note: Requires system firmware greater than 1.13
A6961-67201 A6961-69201
A6961-60004 PCA, 16 slot Memory Board A6961-67004 A6961-69004
A6961-60104 PCA, 16 slot Memory Board, 4GB DIMM capable
Note: Requires system firmware greater than 1.13
A6961-67104 A6961-69104
A7124-04001 PCA, 32 slot Memory Board A7124-67001 A7124-69001
A6961-04005 PCA, 32 slot Memory Board, 4GB DIMM capable
Note: Requires system firmware greater than 1.13
A6961-60005 PCA, Midplane Riser Board A6961-67005 None
