HP P2000 G3 Cli Reference Guide

436 XML API basetype properties
Example
# show ports
...
<OBJECT basetype="port" name="ports" oid="1" format="rows">
<PROPERTY name="durable-id" type="string">hostport_A1</PROPERTY>
<PROPERTY name="controller" key="true" type="string">A</PROPERTY>
<PROPERTY name="controller-numeric" key="true" type="string">1</PROPERTY>
<PROPERTY name="port" key="true" type="string">A1</PROPERTY>
<PROPERTY name="port-type" type="string">FC</PROPERTY>
<PROPERTY name="port-type-numeric" type="string">6</PROPERTY>
<PROPERTY name="media" type="string">FC(P)</PROPERTY>
<PROPERTY name="target-id" type="string">207000c0ff143286</PROPERTY>
<PROPERTY name="status" type="string">Up</PROPERTY>
<PROPERTY name="status-numeric" type="string">0</PROPERTY>
<PROPERTY name="actual-speed" type="string">4Gb</PROPERTY>
<PROPERTY name="actual-speed-numeric" type="string">2</PROPERTY>
<PROPERTY name="configured-speed" type="string">Auto</PROPERTY>
<PROPERTY name="configured-speed-numeric" type="string">3</PROPERTY>
<PROPERTY name="health" type="string">OK</PROPERTY>
<PROPERTY name="health-numeric" type="string">0</PROPERTY>
<PROPERTY name="health-reason" type="string"></PROPERTY>
<PROPERTY name="health-recommendation" type="string"></PROPERTY>
...
</OBJECT>
...
Embedded basetypes
• fc-port
• iscsi-port
• sas-port
health-reason string If Health is not OK, the reason for the health state.
health-
recommendation
string If Health is not OK, the recommended actions to take to resolve the health issue.
Table 52 port properties (continued)
Name Type Description

HP P2000 G3 Specifications

General

Model	P2000 G3
Category	Storage
Drive Support	SAS, SATA
Host Interface	iSCSI, Fibre Channel, SAS
Form Factor	2U
RAID Levels	0, 1, 5, 6, 10
Cache	2 GB
Drive Bays	12 (SFF), 24 (SFF), 12 (LFF)
Cache Memory	2GB per controller
Operating Temperature	10°C to 35°C
Power Supply	Redundant
Expansion Options	Disk Enclosures
