RAID Configuration and Management
Help Information
IMPORTANT: When running the Configuration Utility, you may see RAID 0+1 displayed in
place of RAID 1+0. RAID 0+1 and RAID 1+0 are used synonymously in this utility.
The Help window displays hints on available options and provides a list of keys that
you can use to perform tasks, such as the following:
Switch Windows (Tab)—switches the control back and forth between the Array
Information and the Physical Drive Information windows.
·
·
·
·
Auto Configure RAID 0 (F1)—automatically creates and configures a striped
array based on the available physical drives installed.
Auto Configure RAID 1 (F2)—automatically creates and configures a mirrored
array based on the available physical drives installed. You must have a minimum
of two free hard drives in the array.
Auto Configure RAID 1+0 (F3)—automatically creates and configures a RAID
1+0 array based on the available physical drives installed. You must have four
hard drives in the array.
IMPORTANT: All previous settings are lost when the Auto Configure option is run for RAID
0, RAID 1, and RAID 1+0 arrays.
HP ProLiant ML310 Server Setup and Installation Guide 6-5
