LED Indicators, Switches, and Jumpers
Network Controller LEDs
The network controller LEDs are located on the back of the server. They provide the
following information:
If the server is linked to the network ·
· If there is current network activity
Refer to the Servers Troubleshooting Guide for more information on troubleshooting
network controller problems.
1
2
Figure E-3: Network controller LEDs
Table E-3: Network Controller LEDs
Item Description Status Means
1 Network activity
LED
Off No network
activity
Flashing Network activity
2 Network link
LED
Off No network link
On Linked to
network
HP ProLiant ML310 Server Setup and Installation Guide E-7
