HP ProLiant ML310 Setup And Installation Guide

Hardware Options Installation
Preparing the Server
Before installing or removing any options, prepare the server by performing the
following procedures.
Powering Down the Server
To power down the server:
CAUTION: Failure to follow these instructions could result in damage to
equipment or loss of information.
1. Back up the server data and record configuration information.
2. Shut down the operating system as directed in the operating system instructions.
3. Power down the server by pressing the power button on the front of the server, if
necessary.
4. Remove the power cord.
WARNING: To reduce the risk of injury from electric shock or damage to the
equipment when installing hardware, be sure that the power to the server is
turned off. Remove any AC power cords to completely disconnect power from
the server. The front panel power button may not completely remove power to
the server.
5. Disconnect any other external equipment from the server.
3-2 HP ProLiant ML310 Server Setup and Installation Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: d-ch3.doc
Codename: Son of Beast Part Number: 274431-002 Last Saved On: 11/22/02 1:58 PM

HP ProLiant ML310 Specifications

General

Form Factor	Tower
Processor Sockets	1
Maximum Memory	32GB
Memory Slots	4
Storage Controller	HP Dynamic Smart Array B120i
Processor	Intel Xeon E3-1200 series
Memory Type	DDR3
RAID Support	RAID 0, 1, 10
Storage	Up to 4 LFF (3.5-inch) drives
Hard Drive Interface	SATA
Network	1Gb Ethernet
Power Supply	350W
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Expansion Slots	1 x PCIe 2.0 x1
