Server Features
Rear Panel Connectors
Figure 1-4 and Table 1-3 show the rear panel connectors.
1
2
3
4
5
6
7
8
9
Figure 1-4: Rear panel connectors
Table 1-3: Rear Panel Connectors
Item Connector Item Connector
1 Power cord 6 Video
2 Mouse 7 USB ports (2)
3 Keyboard 8 RJ-45 Ethernet
4 Serial port
connector B
9 Parallel port
5 Serial port
connector A
1-6 HP ProLiant ML310 Server Setup and Installation Guide
