HP ProLiant ML310 Setup And Installation Guide

Hardware Options Installation
Removing a Hard Drive From a Hard Drive Bay
To remove a 3.5-inch hard drive:
1. Follow the steps in “Removing the Access Panel” in this chapter.
2. Disconnect the power and data cables from the back of all devices in the
hard drive compartment.
Figure 3-5 illustrates cable removal from SCSI hard drives.
Figure 3-5: Disconnecting the hard drive cables (SCSI
model)
3-8 HP ProLiant ML310 Server Setup and Installation Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: d-ch3.doc
Codename: Son of Beast Part Number: 274431-002 Last Saved On: 11/22/02 1:58 PM

HP ProLiant ML310 Specifications

General

Form Factor	Tower
Processor Sockets	1
Maximum Memory	32GB
Memory Slots	4
Storage Controller	HP Dynamic Smart Array B120i
Processor	Intel Xeon E3-1200 series
Memory Type	DDR3
RAID Support	RAID 0, 1, 10
Storage	Up to 4 LFF (3.5-inch) drives
Hard Drive Interface	SATA
Network	1Gb Ethernet
Power Supply	350W
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Expansion Slots	1 x PCIe 2.0 x1
