Hardware Options Installation
1
1
2
Figure 3-18: Removing the CD-ROM drive
e. Insert the CD-ROM drive into the third media bay.
Figure 3-19: Moving the CD-ROM drive
IMPORTANT: The drive cage can be installed only in the top two bays.
Be sure to install the rails on the drive cage using the screws that ship with the two-bay
hot-plug SCSI drive cage option kit, rather than the screws removed from the rails.
Be sure to install the right-hand rail on the left side of the drive cage, and the left-hand rail on
the right side of the drive cage.
3-22 HP ProLiant ML310 Server Setup and Installation Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: d-ch3.doc
Codename: Son of Beast Part Number: 274431-002 Last Saved On: 11/22/02 1:58 PM
