Hardware Options Installation
Installing an Expansion Board
Figure 3-21 and Table 3-1 identify the location of expansion slots.
1
2
3
4
Table 3-1: Expansion Slots
Item Slot Type Slot Number
1 3.3-volt, 33-MHz 64-bit PCI 1
2 3.3-volt, 33-MHz 64-bit PCI 2
3 3.3-volt, 33-MHz 64-bit PCI 3
4 3.3-volt, 33-MHz 64-bit PCI 4
Figure 3-21: Expansion slots
3-24 HP ProLiant ML310 Server Setup and Installation Guide
