HP ProLiant ML310 Setup And Installation Guide

Cabling Guidelines
SCSI Cabling
IMPORTANT: The cabling procedures in this section apply only to SCSI models of the
ProLiant ML310 server or ATA models with a SCSI option board. Refer to the section, “ATA
Cabling,” in this chapter for information on cabling ATA models.
ATA models with a SCSI option board require a SCSI cable not included with the SCSI board
option kit. Refer to the HP ProLiant ML310 Server Cabling Matrix for cable information specific
to your model.
Consider the following guidelines when adding SCSI devices to the server:
As a general rule, a maximum of seven devices may be added per channel. The
server is equipped with one integrated Wide Ultra3 SCSI channel.
·
·
·
Be sure to remove all terminating jumpers from third-party SCSI devices.
You must manually set the SCSI ID on each device to a unique value in the range
of 0 through 6 for each SCSI bus. Refer to the documentation provided with the
device for instructions on how to set the SCSI ID.
4-2 HP ProLiant ML310 Server Setup and Installation Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: e-ch4.doc
Codename: Son of Beast Part Number: 274431-002 Last Saved On: 11/22/02 2:02 PM

HP ProLiant ML310 Specifications

General

Form Factor	Tower
Processor Sockets	1
Maximum Memory	32GB
Memory Slots	4
Storage Controller	HP Dynamic Smart Array B120i
Processor	Intel Xeon E3-1200 series
Memory Type	DDR3
RAID Support	RAID 0, 1, 10
Storage	Up to 4 LFF (3.5-inch) drives
Hard Drive Interface	SATA
Network	1Gb Ethernet
Power Supply	350W
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Expansion Slots	1 x PCIe 2.0 x1
