Cabling Guidelines
Internal SCSI Components
Before cabling devices, note the removable media and hard drive compartment
locations, identified in Figure 4-2 and Table 4-1. For information about installing
optional SCSI devices, refer to Chapter 3, “Hardware Options Installation,” or the
documentation included with the device.
2
1
3
Figure 4-2: Internal SCSI components
Table 4-1: Internal SCSI Components
Item Description
1 Removable media bay area
2 Hard drive bay area
3 Internal SCSI connector A
4-4 HP ProLiant ML310 Server Setup and Installation Guide
