Cabling Guidelines
Identifying ATA Components
ATA Cable Components
The ATA cable shown in Figure 4-8 supports up to two ATA devices. Two cables are
included with ATA models of the server.
1
2
Figure 4-8: ATA cable connectors
Table 4-2: ATA Cable Connectors
Item Connector
1 Device 0 (primary)
2 Device 1 (secondary)
NOTE: Refer to “Drive Connection Tips” in Chapter 6 for more information on connecting ATA
cables.
HP ProLiant ML310 Server Setup and Installation Guide 4-11
