LED Indicators, Switches, and Jumpers
Table E-2: System Board LEDs
Item Description Status
1 Processor power
connector not installed
Off = Installed.
Amber = Power connector not
installed.
2 Second power connector
not installed
Off = Installed.
Amber = Power connector not
installed.
3 AC power Off = The AC power cord is not
plugged into the power supply, the
power supply connector is not
attached to the system board, or the
power supply failed.
Green = Power supply is attached to
AC power.
4 CPU 1 failure or failure Off = CPU 1 is functioning.
Amber = CPU 1 failed or is missing.
5 Processor thermal failure Off = Processor temperature is
normal.
Amber = Thermal trip for
processor 1 detected. Refer to
POST error messages for
appropriate instructions.
6 DIMM 4 pre-failure/failure Off = DIMM 4 is functioning.
Amber = DIMM 4 failed.
7 DIMM 3 pre-failure/failure Off = DIMM 3 is functioning.
Amber = DIMM 3 failed.
8 DIMM 2 pre-failure/failure Off = DIMM 2 is functioning.
Amber = DIMM 2 failed.
9 DIMM 1 pre-failure/failure Off = DIMM 1 is functioning.
Amber = DIMM 1 failed.
continued
HP ProLiant ML310 Server Setup and Installation Guide E-5
