Specifications
Minimum Hardware Configuration
Be sure that the server meets the requirements for minimum hardware configuration.
During the troubleshooting process, it may be necessary to reduce the server to its
minimum configuration, reinstalling options one at a time to determine the cause of
failure.
Table F-2: Minimum Hardware Configuration
Component Minimum Specifications
Processors A processor must be installed in processor
socket 1.
Fans A system fan and CPU heatsink fan should be
installed and connected to the system board.
Memory At least one slot must be populated with a
128-MB 200/266-MHz ECC Registered PC2100
DDR SDRAM DIMM.
Note: The maximum memory configuration is 4 x 1-GB memory modules.
Also refer to the HP ProLiant ML310 Server Maintenance and Service Guide at
www.compaq.com/support
HP ProLiant ML310 Server Setup and Installation Guide F-3
HP CONFIDENTIAL
Writer: Ted Weiman File Name: m-appf.doc
Codename: Son of Beast Part Number: 274431-002 Last Saved On: 11/22/02 2:11 PM

HP ProLiant ML310 Specifications

General

Form Factor	Tower
Processor Sockets	1
Maximum Memory	32GB
Memory Slots	4
Storage Controller	HP Dynamic Smart Array B120i
Processor	Intel Xeon E3-1200 series
Memory Type	DDR3
RAID Support	RAID 0, 1, 10
Storage	Up to 4 LFF (3.5-inch) drives
Hard Drive Interface	SATA
Network	1Gb Ethernet
Power Supply	350W
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Expansion Slots	1 x PCIe 2.0 x1
