Cabling Guidelines
Table 4-4: ATA Cabling Sequence
Step Channel/Cable Cable Connector Drive Location
1 ATA/100 RAID
primary controller
Device 0 Hard drive bay 2
2 ATA/100 RAID
secondary
controller
Device 0 Media bay 3
3 ATA/100 RAID
primary controller
Device 1 Hard drive bay 3
4 ATA/100 RAID
secondary
controller
Device 1 Media bay 4
Note: Refer to Chapter 1, “Server Features,” for drive bay locations.
4. Secure the next available power connector to the hard drive or ATA device.
