Server Features
Network Interface Controller Connector LEDs
Figure 1-5 and Table 1-4 show the network interface controller (NIC)
connector LEDs.
1
2
Figure 1-5: NIC connector
Table 1-4: NIC Connector LEDs
Item LED
1 Network activity
2 Network link
HP ProLiant ML310 Server Setup and Installation Guide 1-7
HP CONFIDENTIAL
Writer: Ted Weiman File Name: b-ch01.doc
Codename: Son of Beast Part Number: 274431-002 Last Saved On: 11/22/02 1:53 PM
