HP ProLiant ML310 - Figure 3-9: Locating the Hard Drive Screws

Hardware Options Installation
5. If applicable, remove all terminating jumpers from third-party SCSI devices (HP
SCSI cables are terminated).
NOTE: Using a non-LVD (single-ended) SCSI device impacts the SCSI bus performance of
the server. Any SCSI devices that are Wide-Ultra or older are single-ended.
6. Locate the hard drive screws on the front of the chassis (1).
1
Figure 3-9: Locating the hard drive screws
3-12 HP ProLiant ML310 Server Setup and Installation Guide
