Hardware Options Installation
6. Slide the drive tray into the removable media bay (1), and then secure it with a
screw on each side of the drive tray (2).
1
2
2
Figure 3-12: Installing a hard drive into a removable
media bay
7. Connect the power and data cables to the back of all devices. Refer to Chapter 4,
“Cabling Guidelines,” for cabling information specific to the server model.
8. Replace the access panel and the front bezel.
9. Restore power to the server.
HP ProLiant ML310 Server Setup and Installation Guide 3-15
HP CONFIDENTIAL
Writer: Ted Weiman File Name: d-ch3.doc
Codename: Son of Beast Part Number: 274431-002 Last Saved On: 11/22/02 1:58 PM
