Hardware Options Installation
Installing a Memory Module
The server comes standard with one ECC Registered PC2100 DDR SDRAM DIMM.
Additional DIMMs are available to upgrade the memory up to 4 GB. The server has
four DIMM sockets located on the system board.
1234
Figure 3-26: Locating DIMM sockets
Table 3-2: DIMM Sockets
Item Description
1 DIMM socket 1
2 DIMM socket 2
3 DIMM socket 3
4 DIMM socket 4
HP ProLiant ML310 Server Setup and Installation Guide 3-29
