HP ProLiant ML310 Setup And Installation Guide

Cabling Guidelines
ATA Cabling
IMPORTANT: The cabling procedures in this section apply only to ATA models of the server.
Refer to “SCSI Cabling” in this chapter for information on cabling SCSI models.
ATA models with a SCSI option board require a SCSI cable not included with the option kit.
Refer to the HP ProLiant ML310 Server Cabling Matrix for cable information specific to your
model.
Consider the following guidelines when adding ATA devices to the ProLiant ML310
server:
A maximum of two devices may be added per channel. The server is equipped
with two integrated ATA/100 RAID channels.
·
·
·
Jumpers on ATA devices should be set to Cable Select (CS), enabling primary
and secondary devices to be determined by the cable. Refer to Figure 4-8 for
ATA cable information.
Connect ATA hard drives only to the Integrated ATA/100 RAID controller
channels. Do not connect other peripherals to the Integrated ATA/100 RAID
controller channels.
4-10 HP ProLiant ML310 Server Setup and Installation Guide
HP CONFIDENTIAL
Writer: Ted Weiman File Name: e-ch4.doc
Codename: Son of Beast Part Number: 274431-002 Last Saved On: 11/22/02 2:02 PM

HP ProLiant ML310 Specifications

General

Form Factor	Tower
Processor Sockets	1
Maximum Memory	32GB
Memory Slots	4
Storage Controller	HP Dynamic Smart Array B120i
Processor	Intel Xeon E3-1200 series
Memory Type	DDR3
RAID Support	RAID 0, 1, 10
Storage	Up to 4 LFF (3.5-inch) drives
Hard Drive Interface	SATA
Network	1Gb Ethernet
Power Supply	350W
Operating System Support	Red Hat Enterprise Linux, SUSE Linux Enterprise Server
Expansion Slots	1 x PCIe 2.0 x1
