HP VSR1000 Configuration Guide

235
<SwitchB> system-view
[SwitchB] bgp 65009
[SwitchB-bgp] router-id 2.2.2.2
[SwitchB-bgp] peer 3.1.1.2 as-number 65008
[SwitchB-bgp] peer 3.3.3.3 as-number 65009
[SwitchB-bgp] peer 3.3.3.3 connect-interface loopback 0
[SwitchB-bgp] network 9.1.1.0 255.255.255.0
[SwitchB-bgp] quit
[SwitchB] ip route-static 3.3.3.3 32 9.1.1.2
# Configure Switch C.
<SwitchC> system-view
[SwitchC] bgp 65009
[SwitchC-bgp] router-id 3.3.3.3
[SwitchC-bgp] peer 3.1.2.2 as-number 65008
[SwitchC-bgp] peer 2.2.2.2 as-number 65009
[SwitchC-bgp] peer 2.2.2.2 connect-interface loopback 0
[SwitchC-bgp] network 9.1.1.0 255.255.255.0
[SwitchC-bgp] quit
[SwitchC] ip route-static 2.2.2.2 32 9.1.1.1
# Display the BGP routing table on Switch A.
[SwitchA] display bgp routing-table
Total Number of Routes: 3
BGP Local router ID is 1.1.1.1
Status codes: * - valid, ^ - VPNv4 best, > - best, d - damped,
h - history, i - internal, s - suppressed, S - Stale
Origin : i - IGP, e - EGP, ? – incomplete
Network NextHop MED LocPrf PrefVal Path/Ogn
*> 8.1.1.0/24 0.0.0.0 0 0 i
*> 9.1.1.0/24 3.1.1.1 0 0 65009i
* 3.1.2.1 0 0 65009i
{ T h e o u t p u t s h ow s t w o va l i d r o u t e s t o d e s t i n a t i o n 9.1.1.0 / 24 : t h e ro u t e w i t h n e x t h o p 3.1.1.1 i s
marked with a greater-than sign (>), indicating it is the best route (because the ID of Switch B
is smaller); the route with next hop 3.1.2.1 is marked with only an asterisk (*), indicating it is a
valid route, but not the best.
{ By using the display ip routing-table command, you can find only one route to 9.1.1.0/24 with
next hop 3.1.1.1 and outbound interface VLAN-interface 200.
3. On Switch A, configure the number of ECMP routes destined for AS 65009 to improve link
utilization.
# Configure Switch A.
[SwitchA] bgp 65008
[SwitchA-bgp] balance 2
[SwitchA-bgp] quit
4. Verify the configuration:
