HP VSR1000 Configuration Guide

37
Task Command Remarks
Display RIP current status and
configuration information.
display rip [ process-id |
vpn-instance vpn-instance-name ]
[ | { begin | exclude | include }
regular-expression ]
Available in any view
Display all active routes in RIP
database.
display rip process-id database [ |
{ begin | exclude | include }
regular-expression ]
Available in any view
Display RIP interface information.
display rip process-id interface
[ interface-type interface-number ]
[ | { begin | exclude | include }
regular-expression ]
Available in any view
Display routing information about
a specified RIP process.
display rip process-id route
[ ip-address { mask | mask-length }
| peer ip-address | statistics ] [ |
{ begin | exclude | include }
regular-expression ]
Available in any view
Reset a RIP process. reset rip process-id process Available in user view
Clear the statistics of a RIP process. reset rip process-id statistics Available in user view
RIP configuration examples
Configuring RIP version
Network requirements
As shown in Figure 10, enable RIPv2 on all interfaces on Switch A and Switch B.
Figure 10 Network diagram
Configuration procedure
1. Configure an IP address for each interface. (Details not shown.)
2. Configure basic RIP functions:
# Configure Switch A.
[SwitchA] rip
[SwitchA-rip-1] network 192.168.1.0
[SwitchA-rip-1] network 172.16.0.0
[SwitchA-rip-1] network 172.17.0.0
[SwitchA-rip-1] quit
# Configure Switch B.
[SwitchB] rip
