HP VSR1000 Configuration Guide

11
Configuration guidelines
• FRR takes effect only for static routes that have both an output interface and next hop.
• Do not use FRR and BFD at the same time.
Configuration procedure
To configure static route FRR:
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Configure the source address
of echo packets.
bfd echo-source-ip ip-address
Not configured by default.
For more information about this
command, see High Availability
Command Reference.
3. Configure static route FRR.
ip route-static [ vpn-instance
vpn-instance-name ] fast-reroute
route-policy route-policy-name
Not configured by default.
Displaying and maintaining static routes
Task Command Remarks
Display information of static
routes.
display ip routing-table protocol static [ inactive |
verbose ] [ | { begin | exclude | include }
regular-expression ]
Available in any
view
Delete all the static routes.
delete [ vpn-instance vpn-instance-name ]
static-routes all
Available in
system view
For more information about the display ip routing-table protocol static [ inactive | verbose ] [ | { begin
| exclude | include } regular-expression ] command, see Layer 3—IP Routing Command Reference.
Static route configuration examples
Basic static route configuration example
Network requirements
Configure static routes in Figure 2 for interconnection between any two hosts.
