HP VSR1000 Configuration Guide

252
State: Invalid GotQ Age: 00h08m54s
Tag: 0
Destination: 1.1.1.0/24
Protocol: O_ASE Process ID: 1
Preference: 150 Cost: 1
IpPrecedence: QosLcId:
NextHop: 3.0.2.1 Interface: Vlan-interface101
BkNextHop: 0.0.0.0 BkInterface:
RelyNextHop: 0.0.0.0 Neighbor : 0.0.0.0
Tunnel ID: 0x0 Label: NULL
BKTunnel ID: 0x0 BKLabel: NULL
State: Inactive Adv Age: 00h14m10s
Tag: 1
Destination: 1.1.1.0/24
Protocol: O_ASE Process ID: 1
Preference: 150 Cost: 1
IpPrecedence: QosLcId:
NextHop: 2.0.2.1 Interface: Vlan-interface201
BkNextHop: 0.0.0.0 BkInterface:
RelyNextHop: 0.0.0.0 Neighbor : 0.0.0.0
Tunnel ID: 0x0 Label: NULL
BKTunnel ID: 0x0 BKLabel: NULL
State: Inactive Adv Age: 00h14m10s
Tag: 1
The output shows that Switch A and Switch C communicate through Switch B, and Switch C has
two routes to reach network 1.1.1.0/24: Switch C<—>Switch B<—>Switch A, which is the active
route; Switch C<—>Switch D<—>Switch A, which is the backup route.
When the link between Switch A and Switch B fails, Switch C can quickly detect the link failure.
# Display route 1.1.1.0/24 on Switch C.
<SwitchC> display ip routing-table 1.1.1.0 24 verbose
Routing Table : Public
Summary Count : 1
Destination: 1.1.1.0/24
Protocol: BGP Process ID: 0
Preference: 0 Cost: 100
NextHop: 2.0.1.1 Interface: Vlan-interface201
BkNextHop: 0.0.0.0 BkInterface:
RelyNextHop: 2.0.2.1 Neighbor : 2.0.1.1
Tunnel ID: 0x0 Label: NULL
State: Active Adv Age: 00h09m54s
Tag: 0
The output shows that Switch A and Switch C communicate through Switch D, and Switch C has
one route Switch C<—>Switch D<—>Switch A to reach network 1.1.1.0/24.
