HP VSR1000 Configuration Guide

404
Ste
p
Command Remarks
2. Configure a static route for a
VPN instance.
• ip route-static dest-address { mask |
mask-length } { gateway-address |
interface-type interface-number
[ gateway-address ] | vpn-instance
d-vpn-instance-name gateway-address }
[ preference preference-value ] [ tag tag-value ]
[ description description-text ]
• ip route-static vpn-instance
s-vpn-instance-name&<1-6> dest-address
{ mask | mask-length } { gateway-address
[ public ] | interface-type interface-number
[ gateway-address ] | vpn-instance
d-vpn-instance-name gateway-address }
[ preference preference-value ] [ tag tag-value ]
[ description description-text ]
Use either
command.
3. Configure the default
precedence for static routes.
ip route-static default-preference
default-preference-value
Optional.
60 by default.
Configuring RIP between MCE and PE
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Create a RIP process for
a VPN instance and
enter RIP view.
rip [ process-id ] vpn-instance
vpn-instance-name
N/A
3. Enable RIP on the
interface attached to
the specified network.
network network-address
By default, RIP is disabled on
an interface.
4. Redistribute the VPN
routes.
import-route protocol [ process-id ]
[ allow-ibgp ] [ cost cost | route-policy
route-policy-name | tag tag ] *
By default, no route of any
other routing protocol is
redistributed into RIP.
5. Configure the default
cost value for the
redistributed routes.
default cost value
Optional.
0 by default.
Configuring OSPF between MCE and PE
Ste
p
Command Remarks
1. Enter system view.
system-view N/A
2. Create an OSPF process
for a VPN instance and
enter OSPF view.
ospf [ process-id | router-id
router-id | vpn-instance
vpn-instance-name ] *
N/A
