HPE FlexNetwork MSR Series Guide

148
Table 236 Specifications for 1000-Mbps BIDI transceiver modules
Produ
ct
code
Descripti
on
Center
wavelengt
h (nm)
Fiber
mod
e
Optical
fiber
diamete
r (µm)
Transmis
sion
distance
Interface specifications
(dBm)
Output
optical
power
Recei
ve
sensit
ivity
Optica
l
satura
tion
JD098
B
HPE X120
1G SFP
LC BX
10-U
Transceive
r
1310
(TX)
1490
(RX)
SMF 9/125
10 km
(6.21
miles)
–9 to –3 ≤ –18.7 ≤ –3
JD099
B
HPE X120
1G SFP
LC BX
10-D
Transceive
r
1490
(TX)
1310
(RX)
Connecting an optical fiber
CAUTION:
•
Never stare into an open optical Ethernet interface, because invisible rays might be emitted from the
optical Ethernet interface.
•
Cover the dust cover if no optical fiber connector is connected to the optical Ethernet interface.
To connect an optical fiber
1. Insert the SFP/XFP transceiver module to the SFP/XFP interface on the interface module or
service module.
2. Identify the Rx and Tx ports on the SFP transceiver.
a. Plug the LC connector at one end of one fiber cable into the Rx port of the router and the LC
connector at the other end into the Tx port of the peer device.
b. Plug the LC connector at one end of another fiber cable into the Tx port of the router and the
LC connector at the other end to the Rx port of the peer device.
3. View the LINK LED after connection.
• If the LED is on, the optical fiber link is present.
• If the LED is off, no link is present. This might be because the TX and Rx port of the optical fiber
are not connected correctly. In this case, connect the optical fiber again.
