Table 169 LED description for the
FIC-16FSW/FIC-16FSW-PoE/DFIC-24FSW/DFIC-24FSW-PoE GE ports
Off No link is present.
Steady green A 1000 Mbps link is present, but no data is being transmitted and received.
Flashing green A 1000 Mbps link is present and data is being transmitted and received (ACT).
Steady yellow A 100 Mbps link is present, but no data is being transmitted and received.
Flashing yellow A 100 Mbps link is present and data is being transmitted and received (ACT).
Table 170 LED description for the
FIC-16FSW/FIC-16FSW-PoE/DFIC-24FSW/DFIC-24FSW-PoE fiber ports
Off No link is present.
Steady green A link is present, but no data is being transmitted and received.
Flashing green A link is present and data is being transmitted and received (ACT).
Steady yellow Error prompt
The two GE ports on the DFIC-24FSW-PoE do not support PoE.
Interface cables and connection methods
For more information about the Ethernet interface cables and connection methods, see "Ethernet
interface."
Ethernet interface module
• FIC-2FE
• FIC-4FE
• FIC-1GBE
• FIC-2GBE
• FIC-1GEF
• FIC-2GEF
FIC-2FE/FIC-4FE
Introduction
The 2-port and 4-port 10Base-T/100Base-TX fast Ethernet interface modules (FIC-2FE, and
FIC-4FE) are typically used for communication between the router and LAN.
Interface specifications
Table 171 Interface specifications
