HPE FlexNetwork MSR Series - Voice Interface Module

129
Item
Specification
FIC-8ASE
FIC-16ASE
Cable type
• AUX cable
• Ethernet straight-through cable
• FIC-8ASE/FIC-16ASE dumb terminal cable
Min. baud rate (bps) 300
Max. baud rate (bps) 115.2 k
Service supported
• Dialup through modem
• Backup
• Terminal access service
• Asynchronous leased line
Interface LEDs
Figure 151 FIC-8ASE panel
Figure 152 FIC-16ASE panel
The FIC-8ASE/FIC-16ASE has one LED for each port. On means a link is present. Off means data is
being transmitted and/or received.
Interface cables and connection methods
For more information about asynchronous serial port cables, see "Asynchronous serial ports."
Voice interface module
• FIC-4FXS
• FIC-4FXO
• FIC-4E&M
• FIC-24FXS
• FIC-2VE1
• FIC-2VT1
• FIC-1VE1
• FIC-1VT1
