50
Steady yellow A 100 Mbps link is present, but no data is being transmitted and received.
Flashing yellow A 100 Mbps link is present and data is being transmitted and received (ACT).
Table 76 Description for the DMIM-24FSW/DMIM-24FSW-PoE fiber interface LEDs
Off No link is present.
Steady green A link is present, but no data is being transmitted and received.
Flashing green A link is present and data is being transmitted and received (ACT).
Steady yellow Error prompt
The two GE interfaces on the DMIM-24FSW-PoE do not support PoE.
Interface cables and connection methods
For more information about the Ethernet interface cables and connection methods, see "Ethernet
interface."
For more information about fiber ports, optical fibers, and the connection methods, see "Fiber port."
Ethernet interface module
• MIM-2FE
• MIM-4FE
• MIM-2GBE
MIM-2FE/MIM-4FE
Introduction
The 2/4-port 10/100Base-TX Fast Ethernet interface module (MIM-2FE/MIM-4FE) completes
communications between routers and LANs.
Interface specifications
Table 77 Interface specifications
Item
Connector RJ-45
Type of interface MDI
Number of connectors 2 4
Transmission distance
100 m (328.08 ft) over category-5 twisted pair cables (both
crossover and straight-through)
Operating mode 10/100 Mbps autosensing, full duplex/ half-duplex
