32
LED
Description
HSDPA
• Steady yellow means the service is valid.
• Off means no service.
Antenna, interface cable, and the connection method
For more information about SIC-3G-GSM interface cables and connection methods, see "WLAN
interface."
Installing a SIM card
1. Push the 3G SIM card holder in the direction marked "OPEN" so the holder projects upwards.
Do not insert the 3G SIM card to the card holder before projecting the card holder up. Do not
forcibly lift the holder.
2. Insert the 3G SIM card along the slide rails to the holder.
3. Put down the holder and push the holder in the direction marked "LOCK" to lock the card in
position.
4. Position the 3G SIM card socket cover and fasten the screws on the cover.
5. Execute the display cellular [slot]/0 all command after the router is started. When "SIM Status
= OK" appears in the output information, the SIM card is identified.
SIC-3G-HSPA
Introduction
The SIC-3G-HSPA module provides access to 3G networks. It provides the following features:
• GPRS
• EDGE
• UMTS
• HSDPA
Interface specifications
Table 55 Interface specifications
Item
Specification
Connector type
TNC: For connecting an antenna and accessing WLANs.
RJ-45: For connecting to a third-party WLAN debugging and testing software
such as CAIT of Qualcomm.
Number of connectors
2 TNC RF
1 RJ-45
Interface standard
TNC RF: Omni antenna, supporting GPRS/EDGE/UMTS/HSDPA.
RJ-45: RS232
Cable type
TNC RF: None
RJ-45: AUX cable
Rates
• HSDPA (downlink: 7.2 Mbps)
• HSUPA (uplink: 5.76 Mbps)
• UMTS (downlink: 384 Mbps, uplink: 384 Kbps)
• EDGE (downlink: 236.8 Kbps, uplink: 236.8 Kbps)
• GPRS (downlink: 85.6 Kbps, uplink: 85.6 Kbps)
Services GPRS/EDGE/UMTS/HSDPA
