5. Execute the display cellular [slot]/0 all command after the router is started. When "SIM Status
= OK" appears in the output information, the SIM module is identified.
SIC-4G-LTE-V (JG742B)
The SIC-4G-LTE-V (JG742B) module provides access to 4G WLANs. It supports the following
services:
• LTE.
• EVDO Release 0 & A.
• UMTS.
• HSPA+.
• DC-HSPA+.
• Quad-band EDGE.
• GPRS.
• GSM.
• GNSS.
Interface specifications
Table 61 Interface specifications
Item
Specification
Connector type
• TNC: Antenna connector for accessing WLANs.
• SMA: Antenna connector for accessing GNSS.
• Mini USB Type AB: For connecting to third-party WLAN debugging and testing
software such as CAIT of Qualcomm.
Number of
connectors
• 2 × TNC.
• 1 × SMA.
• 1 × Mini USB Type AB.
Interface standard
• TNC: LTE, UMTS, HSPA+, CDMA 1x, EVDO Release 0 & A, Quad-band EDGE,
GPRS, and GSM.
• SMA: GNSS.
• Mini USB Type AB: Support for USB devices.
Cable type
• TNC: None.
• SMA: Flexible 174 sized cable.
• Mini USB Type AB: USB console cable.
Services
• LTE.
• EVDO Release 0 & A.
• UMTS.
• HSPA+.
• DC-HSPA+.
• Quad-band EDGE.
• GPRS.
• GSM.
• GNSS.
