HPE FlexNetwork MSR Series Guide

156
Connecting a 4-port E1 120-ohm cable (D25 <----> D15)
1. Connect the D25 connector of the 4-port E1 120-ohm cable to the D25 interface on the interface
module and fasten the bolts to fix the cable.
2. The other end of the cable provides four D15 connectors. Connect them to the D15 interface on
the remote device as needed.
Figure 167 Connecting an 4-port E1 120-ohm cable
T1 interface
CAU
TION:
T
o avoid damages to the interface module or the chassis, make sure you insert the cable into the
correct interface.
Device
(120ohm E1 Port)
1-port E1 120-ohm cable
E1 / E1-F
(120ohm)
4-port E1 120-ohm cable
