Figure 4-54 Securing the low temperature component
----End
4.8 Connecting Pipelines
● The thickness of heat insulation cottons should not be less than 9.2 mm.
● When purchasing water pipes, ensure that the water pipe with thermal
insulation foam warped can go through the ports on the bottom and top
boards.
4.8.1 Notices for Laying Pipes
