Procedure
Step 1 Remove the four M12 screws securing the sheet metal to the pallet using an 18#
socket wrench.
Figure 4-31 Removing the screws
Step 2 Remove the cabinet from the pallet.
----End
4.4.2.2 Removing the Transport Fasteners from the Compressor
Procedure
Step 1 Loosen the three bolts on the compressor transport fasteners using a 13# solid
wrench.
Figure 4-32 Removing the transport fasteners from the compressor
NetCol8000-A(045, 055, 060, 090, 120) In-room Air
Cooled Smart Cooling Product
User Manual 4 System Installation
Issue 05 (2020-10-10) Copyright © Huawei Technologies Co., Ltd. 79
