Step 3 Secure the cable to the right post of the cabinet using cable ties.
Place the sheet metal of the water sensor upwards and its detection board
downwards on the ground.
Figure 4-98 Connecting a cable to the water sensor 1 (for NetCol8000-A045D)
NetCol8000-A(045, 055, 060, 090, 120) In-room Air
Cooled Smart Cooling Product
User Manual 4 System Installation
Issue 05 (2020-10-10) Copyright © Huawei Technologies Co., Ltd. 132
