Figure 11-1 Removing the air lters (downow) (for NetCol8000-A045D)
Figure 11-2 Removing the air lters (upow) (for NetCol8000-A045U)
Step 3 Remove the lter on the left in the same way.
Step 4 Install new air lters in an inverse order.
NO TICE
Install air lters as instructed by the labels thereon and avoid reverse installation.
