ArcGlide THC Instruction Manual 3-3
OPERATION
2
Lifter
Item Control Description
1 Station status light This light is illuminated if the lifter is enabled. The light flashes slowly when there is
an error. It flashes rapidly in Align mode.
When the light is off, the brake is locked and the lifter is disabled.
2 Station enable/disable
switch
Press this switch up to enable the lifter for operation. Press the switch down to
disable the lifter before maintenance, to replace consumables, or to power OFF the
lifter.
If the plasma system is capable and wired appropriately, this switch can also turn on
and off the plasma system.
3 Lifter UP/DOWN
switch
Move this switch up or down to raise or lower the torch.
1
2
3
