Hypertherm ArcGlide Torch Height Control - Optional HMI (090055)

ArcGlide THC Instruction Manual 1-7
SPECIFICATIONS
2
Optional HMI (090055)
Regulatory approvals CE, CSA
Input power
100 VAC to 240 VAC, 50/60 Hz, 40 mA to 20mA,
1Phase,
Hypernet communication Shielded RJ-45 Cat-5e
Operating temperature -10º C to 40º C (14º F to 104º F)
Operating humidity 95% relative humidity
HMI
298.00 mm
(11.73”)
117.60
mm
(4.63”)
130.50 mm
(5.14”)
1.91 kg
(4.20 lb)
65.00 mm
(2.50”)
