Hypertherm ArcGlide Torch Height Control User Manual

ArcGlide THC Instruction Manual 2-15
ArcGlide THC with discrete connection to a Picopath CNC and HPR or HPRXD plasma system
ArcGlide HMI
address 1
AXES 3,4
AXES 1,2
I/O
To CNC RS-422
port, terminate as
required
OEM-supplied
serial cable
DB37 female
HPR control PCB
DB37 male
Cable 223192
without serial
(with red
heatshrink)
Plasma interface (090052)
CNC I/O cable
Shielded Ethernet
cable
ArcGlide control
module address 1
Plasma interface cable
Arc voltage sense wires
Lifter interface cable
ArcGlide lifter
To plasma interface assembly
Cable 223192
without serial
(with red
heatshrink)
OEM-
supplied
serial cable
ArcGlide
HMI address
1
DB37 female
RS-422 serial
port
CNC with Picopath interface and serial communication
Axes 3,4
Axes 1,2
I/O
DB50 male
