2-14 ArcGlide THC Instruction Manual
ArcGlide THC with Hypernet connection to an EDGE Pro CNC and discrete connection to an HPR or HPRXD plasma system
HYPERNET
Plasma interface assembly (090052)
EDGE Pro CNC
DB37 to DB37 cable (123760)
HPR or HPRXD plasma system with discrete plasma interface (090052)
Plasma interface I/O cable
Interlock
Lifter interface cable
Rotary address switch, set to 1
ArcGlide lifter
Shielded Ethernet cable, up to
61 m (200 ft)
ArcGlide control module
DB37
DB37
DB50
Arc voltage sense wires
