1-2 ArcGlide THC Instruction Manual
SPECIFICATIONS
Example of an ArcGlide THC installed on a cutting table with a plasma system and CNC
Note:
The ArcGlide control module and Ethernet switch should be located in an electrical cabinet that is
electrically grounded and environmentally clean.
Plasma system
CNC
ArcGlide HMI
(optional)
Rails
Cutting table GantryWorkpiece
ArcGlide lifter
ArcGlide control
module
Star ground
